Firehose audit log reference

Audit logs and access logs are critical tools for enterprises, providing visibility into system activities, enhancing security, ensuring compliance, and supporting operational efficiency. They are useful for:

1. Security and Threat Detection
2. Compliance and Legal Protection
3. Operational Efficiency and Troubleshooting
4. Accountability and Fraud Prevention
5. Forensic Analysis and Incident Response

Ripple Custody (Wallet) keeps track of audit logs, allowing you to configure an endpoint where to receive a copy. To set up delivery, see Audit logging.

Customer configures an IAM role and a firehose endpoint in Organization settings. During the upload, the following environment specific IAM roles assume the customer configured IAM roles in order to perform PutRecordBatch on the configured firehose endpoint.

Once configured, Ripple Custody (Wallet) will buffer and upload logs in batch every 15 seconds.

Every time you save or enable the configuration, Ripple Custody (Wallet) validates it by delivering a single test record: id is 0, type is 1, orgId is null, and source is audit-service-validation. Filter it out in your pipeline. Disabling the configuration skips validation, so it delivers no test record.

The IAM role that grants access to Ripple Custody (Wallet) to upload logs to AWS Firehose must have following policies:

{
    "Version": "2012-10-17",
    "Statement": [
        {
            "Sid": "AllowFirehosePutRecordBatch",
            "Effect": "Allow",
            "Action": "firehose:PutRecordBatch",
            "Resource": "arn:aws:firehose:REGION:ACCOUNT_ID:deliverystream/STREAM_NAME"
        },
        {
            "Sid": "AllowStsGetCallerIdentity",
            "Effect": "Allow",
            "Action": "sts:GetCallerIdentity",
            "Resource": "*"
        }
    ]
}

Additionally, in order to allow Ripple Custody (Wallet) to assume this role, it must have the following IAM trust relationship:

{
    "Version": "2012-10-17",
    "Statement": [
        {
            "Sid": "AllowPalisadeAssumeRole",
            "Effect": "Allow",
            "Principal": {
                "AWS": "arn:aws:iam::PALISADE_ACCOUNT_ID:PALISADE_IAM_RESOURCE_NAME"
            },
            "Action": "sts:AssumeRole"
        }
    ]
}

The type field identifies the kind of event the record carries.

Use source together with type to filter records. Transaction and wallet records use these values:

A transaction collects any required approvals while it's in POLICY_CHECK_PENDING. Records written before approvals moved into the policy check can also carry APPROVAL_CHECK_PENDING and APPROVAL_CHECK_PASSED. See Transaction status changes.

Every record is a JSON object with the following envelope. Payload formats covers the payload fields.

orgId corresponds to your organization on every record except the validation record, where it's null. On access records, userId, deviceId, and requestId describe the initiator of the request where that information exists, and they aren't guaranteed to be present. On transaction and wallet records, userId identifies the creator of the transaction or wallet.

Read the payload from compressedJsonData for every record type:

1. Base64-decode compressedJsonData to get the Brotli-compressed bytes.
2. Brotli-decompress those bytes to get the uncompressed JSON bytes.
3. Parse the result as JSON.
4. Optionally verify integrity: the decompressed byte length must equal originalJsonDataSize, and its SHA-256 must equal originalJsonDataSha256.

Brotli is a standard, widely implemented codec. Node.js decompresses it with the built-in node:zlib module. Python needs the brotli or brotlicffi package. Java, Go, and .NET have established libraries.

import { brotliDecompressSync } from "node:zlib";
import { createHash } from "node:crypto";

function decodeAuditRecord(record) {
  const json = brotliDecompressSync(Buffer.from(record.compressedJsonData, "base64"));

  if (json.length !== record.originalJsonDataSize) {
    throw new Error(`size mismatch for audit record ${record.id}`);
  }
  const sha256 = createHash("sha256").update(json).digest("hex");
  if (sha256 !== record.originalJsonDataSha256) {
    throw new Error(`checksum mismatch for audit record ${record.id}`);
  }

  return JSON.parse(json.toString("utf8"));
}

An access record during the migration window carries both payload representations. jsonData and compressedJsonData decode to the same bytes.

{
  "id": 21119,
  "orgId": "dac59f97-5984-4298-bebd-92c94b6184b4",
  "type": 1,
  "userId": "c1e08d96-07a3-4561-846f-dd5a5c274e29",
  "deviceId": null,
  "requestId": "2aa53531-2124-4501-b9bb-2ed8208ff0e8",
  "jsonData": "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",
  "compressedJsonData": "G6EBAMSP6d5pfzN2F6JbzTZdSQ6+aAtp3WwH7L9tMAh2UcBJaWqBBhJId92FkZRuEwVvD4naEl+T7v1ift9igP1g+xHmbcm2S+Sjr5OeYgzaN23Q/cSjpuTEBxJOFdnPZpFcMhRoFRhwdfGoOsjtI2P4xck0xWPBAHCUcguFpxzf9Un7zjoGHMN2lYNEnWWjj99ledhbMp1xUHjVpej6BmiWQ6iruiLNxF772pEe+3GUUZSOXZeSi93OdHl4z6ZHieBvrjLOEFWGPRRO5vIheiK2UV+HvMSAmnpJPrVhjNT10qe262liFmInTe3xL5JX3JEnZ8QBK/oaf4h24j7uF2WJgTrPCrmEMuezg0QM7Ny/gszv6NVDxkB8Rv/uUOKJCF37Bw==",
  "compressionAlgorithm": "br",
  "compressionVersion": 1,
  "compressionQuality": 6,
  "originalJsonDataSize": 418,
  "originalJsonDataSha256": "3b3c9d6900086fb8c1fa65b8a6b23694a2fa074deceba8d8ac46907ac3ede3bb",
  "source": "api-gateway",
  "receivedAt": "2026-09-21T15:59:08.764753Z",
  "createdAt": "2026-09-21T15:59:08.757472Z"
}

The decoded payload of an access record has the following structure:

{
  "url": "/v2/vaults/8f14e45f-ceea-467a-9c2b-1f0d4a1d2f31/wallets",
  "method": "GET",
  "headers": {
    "Accept": "application/json",
    "User-Agent": "palisade-sdk-python/1.8.0",
    "X-Request-Id": "2aa53531-2124-4501-b9bb-2ed8208ff0e8",
    "X-Forwarded-For": "203.0.113.24",
    "Authorization-Hash": "519df4f7abe189d9f7891c22d120d654"
  },
  "request": {
    "body": ""
  },
  "response": {
    "bodyLength": 1842,
    "statusCode": 200
  },
  "durationMs": 12,
  "remoteAddr": "203.0.113.24"
}

The access payload carries the following fields.

Transaction (type: 3) and wallet (type: 4) records carry only the compressed payload: compressedJsonData and the compression metadata, never jsonData. Read the payload the same way you read it for an access record.

{
  "id": 21124,
  "orgId": "dac59f97-5984-4298-bebd-92c94b6184b4",
  "type": 3,
  "userId": "c1e08d96-07a3-4561-846f-dd5a5c274e29",
  "deviceId": null,
  "requestId": null,
  "compressedJsonData": "GygBAGRz7175aMI12X0OHMLiOv+UY9vyOHzAwALguigLOKAAqM2mE53KQG64w/GvKHzy5hfevuD4hacJB5QtzQctrDoYddvG2nwhD+m5SwuaCif4PBTJt5sltWeLbiyNA9RO3NGnLRq5udVCfbT315hzky61jWOtBjxoLGmXqY0mbyH870j89IW582zD6q6BVlO54prYV59YeVTtTqk9Pa/wn+s3HDBolZzVsUQTVHPCVN84pzUbHLq4ari86eJoWCoyTdG+8CF5NqM7/P8D",
  "compressionAlgorithm": "br",
  "compressionVersion": 1,
  "compressionQuality": 6,
  "originalJsonDataSize": 297,
  "originalJsonDataSha256": "4eb5ec331a4ac4ac5cd0db79f1d9731104d34ac318dc9a25b3a650c454bfc2ea",
  "source": "SIGNED",
  "receivedAt": "2026-09-21T16:02:41.118204Z",
  "createdAt": "2026-09-21T16:02:41.109883Z"
}

The decoded payload wraps the entity that changed — tx for transaction events, wallet for wallet events (abbreviated here):

{
  "tx": {
    "id": "0f3a6c1e-94c2-4f5f-9a6e-2c3b8f0a71d4",
    "walletId": "4b8a7b5e-3a27-4f1a-9a2b-6d5e1c8f2a90",
    "vaultId": "8f14e45f-ceea-467a-9c2b-1f0d4a1d2f31",
    "organizationId": "dac59f97-5984-4298-bebd-92c94b6184b4",
    "createdBy": "c1e08d96-07a3-4561-846f-dd5a5c274e29",
    "createdAt": "2026-09-21T16:02:38.551Z"
  }
}

Audit records previously carried the payload as uncompressed jsonData on access events, and there were no transaction or wallet records. Records now carry Brotli-compressed payloads for every event type. Four format states matter to a consumer.

The envelope fields id, orgId, type, userId, deviceId, requestId, source, receivedAt, and createdAt keep the same meaning in all four states.

{
  "id": 21119,
  "type": 1,
  "jsonData": "eyJ1cmwiOiIvdjIvd2FsbGV0cyIsIm1ldGhvZCI6IkdFVCJ9",
  "source": "api-gateway"
}

jsonData holds base64-encoded uncompressed JSON bytes. No compression fields are present.

{
  "id": 21119,
  "type": 1,
  "jsonData": "eyJ1cmwiOiIvdjIvd2FsbGV0cyIsIm1ldGhvZCI6IkdFVCJ9",
  "compressedJsonData": "ixGAeyJ1cmwiOiIvdjIvd2FsbGV0cyIsIm1ldGhvZCI6IkdFVCJ9Aw==",
  "compressionAlgorithm": "br",
  "compressionVersion": 1,
  "compressionQuality": 6,
  "originalJsonDataSize": 36,
  "originalJsonDataSha256": "7b142d8a802972756e06db628e2e05da2f2d8c027d67d24e343112820aa2e9b2",
  "source": "api-gateway"
}

Both payload fields decode to the same JSON. jsonData holds base64-encoded uncompressed JSON bytes, and Ripple removes it after the deprecation window. compressedJsonData holds base64-encoded Brotli-compressed JSON bytes, and it's the field to read.

{
  "id": 21124,
  "type": 3,
  "compressedJsonData": "GygBAGRz7175aMI12X0OHMLiOv+UY9vyOHzAwALguigLOKAAqM2mE53KQG64w/GvKHzy5hfevuD4hacJB5QtzQctrDoYddvG2nwhD+m5SwuaCif4PBTJt5sltWeLbiyNA9RO3NGnLRq5udVCfbT315hzky61jWOtBjxoLGmXqY0mbyH870j89IW582zD6q6BVlO54prYV59YeVTtTqk9Pa/wn+s3HDBolZzVsUQTVHPCVN84pzUbHLq4ari86eJoWCoyTdG+8CF5NqM7/P8D",
  "compressionAlgorithm": "br",
  "compressionVersion": 1,
  "compressionQuality": 6,
  "originalJsonDataSize": 297,
  "originalJsonDataSha256": "4eb5ec331a4ac4ac5cd0db79f1d9731104d34ac318dc9a25b3a650c454bfc2ea",
  "source": "SIGNED"
}

jsonData is absent. Consumers that require an uncompressed payload must decompress compressedJsonData.

{
  "id": 21119,
  "type": 1,
  "compressedJsonData": "ixGAeyJ1cmwiOiIvdjIvd2FsbGV0cyIsIm1ldGhvZCI6IkdFVCJ9Aw==",
  "compressionAlgorithm": "br",
  "compressionVersion": 1,
  "compressionQuality": 6,
  "originalJsonDataSize": 36,
  "originalJsonDataSha256": "7b142d8a802972756e06db628e2e05da2f2d8c027d67d24e343112820aa2e9b2",
  "source": "api-gateway"
}

After Ripple removes jsonData, access records use the same compressed-only contract as transaction and wallet records. A consumer that already reads compressedJsonData needs no further change.

A single Firehose record must stay below 1,000,000 encoded bytes, counting the complete JSON record and both payload representations.

• When a complete access record reaches 1,000,000 bytes, Ripple Custody (Wallet) clears request.body in the payload, rebuilds both jsonData and compressedJsonData from the reduced payload, and sets legacyJsonDataTruncated to true. originalJsonDataSize and originalJsonDataSha256 then describe the reduced payload, so integrity checks still pass.
• Transaction and wallet records carry only the compressed payload, and Ripple Custody (Wallet) never truncates them.
• Because an access record carries the payload twice during the migration window, request.body is what usually exhausts the budget.
• If a record still reaches 1,000,000 bytes after truncation, Ripple Custody (Wallet) can't deliver it, and delivery to your stream stops. Re-enabling the configuration doesn't clear this state, so contact support with the time your stream stopped. See Delivery guarantees.

• One persisted audit event maps to exactly one Firehose record.
• Delivery is at least once. Deduplicate on id.
• Ripple Custody (Wallet) delivers records approximately every 15 seconds.
• While the configuration is disabled, Ripple Custody (Wallet) delivers nothing. When you re-enable it, Ripple Custody (Wallet) delivers the events it recorded while the configuration was off.
• If delivery keeps failing, Ripple Custody (Wallet) disables the Firehose configuration. Fix the delivery stream or IAM role, and then re-enable the configuration from Settings > Audit logs. See Audit logging.

1. Support for AWS Firehose only
2. Logs are buffered for 15 seconds before sending to firehose
3. Records must stay below 1,000,000 encoded bytes. An oversize access payload loses request.body
